1 in Y-Pattern Swing Check Valve, 150 lb, Bronze Disc, CxC, Bronze
$NIBCO S-433-B 1" 150# CXC BRNZ SWING CHECK VALVE
Swing Check Valves
}
1 in Y-Pattern Swing Check Valve, 150 lb, Bronze Disc, CxC, Bronze
537578
MFG #: S-433-B-1
Product ID:537578
Famous Supply
- Media: Water/Steam
- Pressure Rating: 300 psi
- Series: S-433-B
- Type: Globe Valve
- Nominal Size: 1 in
- End Style: FSWT
- Low Lead Compliance: No
- Body Material: Bronze
The NIBCO® bronze horizontal swing check valve has a Y-pattern design with renewable seat and disc. The swing check valve prevents backflow by automatically closing when fluid reverses direction. It features a screw-in bonnet for accessibility to repair or replace parts. The check valve is recommended for commercial and industrial steam, water, oil and gas services.
- Features
| 150 psi/10.3 bar saturated steam to 366°F/185°C |
| 300 psi/20.7 bar non-shock cold working pressure |
| Y-pattern |
| Renewable bronze disc |
| Regrindable seat |
| Class 150 solder end connections |
